Akuvox E13S Feature-rich and Stylish Entry-Level Door Phone

The Akuvox E13S is a single-button SIP video door phone designed for mid-range residential buildings. It is a perfect blend of sleek design, rich intercom functionality, and ease of installation.

{{shoplineProductReview.avg_score}}( {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}} )

{{amazonProductReview.avg_rating}}( ({{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}) )

The maximum quantity per submit is 99999

This quantity is invalid, please enter a valid quantity.

Sold Out

Please message the shop owner for order details.

Description

Shipping & Payment

Description

E13S Specification

The Akuvox E13S is a single-button SIP video door phone designed for mid-range residential buildings. It is a perfect blend of sleek design, rich intercom functionality, and ease of installation.

Physical & Power

Body Material: Plastic
Camera: 2M pixels, automatic lighting
Button: 1 call button
Wiegand port: Support
RF card reader: 13.56MHz, NFC
Light sensor: 1
Relays out: 1
Inputs: 2
Microphone: 1
Speaker: 1
Ethernet port: RJ45, 10/100Mbps adaptive
Tamper Alarm: Support
8023af Power- over- Ethernet
12V DC connector (if not using PoE)
IP Rating: IP65
Installation: In-Wall or On-Wall
Size: 160x86x25mm
Working Humidity: 10~90%
Working Temperature: -40°C ~ +60°C
Storage Temperature: -40°C ~ + 70°C

Audio

SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec: G.711a, G.711μ
Wideband audio codec: G.722
DTMF: In-band, out-of- band DTMF (RFC2833), SIP Info
Echo Cancellation
Voice Activation Detection
Comfort Noise Generator

Video

Sensor: 1/2.8", CMOS
Pixels: CIF, VGA, 4CIF, 720p, 1080p
Video codec: H.264
Video resolution: up to 1920x1080
Max. image transfer rate: 1080p - 30fps
Viewing angle: 114°(H) / 58°(V)
IR LEDs for picture lighting during dark hours
Compatible to 3rd-party video components, e.g. NVRs

Door Entry Feature

Relays controlled individually by DTMF tones
Camera permanently operational
Auto-night mode with IR LED illumination
White balance: auto
Minimum illumination: 0.1LUX

Networking

Protocols support: IPv4, HTTP,HTTPS, FTP,DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Deployment & Maintenance

Auto- Provisioning
Web management portal
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)

Application Scenario

Apartment/flat intercom with door access control
Remote site entry over Internet
