akubela HyPanel Elite 7 (PG42)

akubela HyPanel Elite 7 (PG42)

．7” touch screen with energy saving mode
．Two-way audio communication with other units in the network
．Smart home controller with ZigBee gateway and IR Control
．Powered by PoE or external source
．Support both US and EU electrical wall box mounting
．Support RS485

{{shoplineProductReview.avg_score}}( {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}} )
{{amazonProductReview.avg_rating}}( ({{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}) )
Quantity Product set quantity
The maximum quantity per submit is 99999
This quantity is invalid, please enter a valid quantity.
Sold Out

Not enough stock.
Your item was not added to your cart.

Not enough stock.
Please adjust your quantity.

{{'products.quick_cart.out_of_number_hint'| translate}}

{{'product.preorder_limit.hint'| translate}}

Limit {{ product.max_order_quantity }} per order.

Only {{ quantityOfStock }} item(s) left.

Please message the shop owner for order details.
Description
Shipping & Payment
Description


HyPanel Elite 7
The akubela HyPanel Elite 7, with a Linux operating system, integrates smart intercom, ZigBee gateway and infrared remote control, provides audio and video communication with door phones via SIP 2.0 protocol. It delivers the ultimate touch screen experience in an unobtrusive, space-saving design featuring a brilliant 7-inch capacitive touch screen display.
Basic Information
  • Model Number: PG42
  • Power Supply: IEEE802.3af PoE & 12VDC
  • Operation System: Linux
  • DDR/Flash: 128MB/256MB
  • Wi-Fi: IEEE802.11 b/g/n/ax, @2.4GHz
  • Ethernet Port: 2×RJ45, 10/100Mbps adaptive
  • ZigBee: ZigBee 3.0
  • ZigBee Sub-Device Limit: 32
  • RS485 Port: Supported
  • Relay Output: 1 gang 0 - 30VDC, rated current: 2A
  • Bell In Port: 1 channel
  • Digital Input: 8 channels
  • Microphone: Single microphone, -42dBV
  • Speaker: Single speaker, 4Ω/2W
  • IR Control Coverage: Horizontal 90°, vertical 90°, 6m
Appearance
  • Material: V0 fireproof PC
  • Screen: 7” touch screen
  • Screen Resolution: 1024×600 pixels
  • Screen Brightness: 300 cd/㎡
Working Environment
  • Environment: For indoor use only
  • Working Humidity: 10% ~ 90%RH, without condensation
  • Working Temperature: -10℃ ~ 45℃
  • Storage Temperature: -20℃ ~ 70℃
  • IP Rating: IP20
Installation
  • Installation: Wall-mounted &Desktop
  • Wall-mounted Standard: EU/UK/US standard
