Akuvox S539 Industry-first Metaverse Android Door Phone

Akuvox S539 Industry-first Metaverse Android Door Phone

Akuvox S539 video door phone, featuring a terraced surface, a multi-functional camera module, and over 15 access control methods, is innovatively built in with an avatar. More convenient, more secure, and more interactive. The Metaverse-Intercom era is coming with S539.

{{shoplineProductReview.avg_score}}( {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}} )
{{amazonProductReview.avg_rating}}( ({{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}) )
Quantity Product set quantity
The maximum quantity per submit is 99999
This quantity is invalid, please enter a valid quantity.
Sold Out

Not enough stock.
Your item was not added to your cart.

Not enough stock.
Please adjust your quantity.

{{'products.quick_cart.out_of_number_hint'| translate}}

{{'product.preorder_limit.hint'| translate}}

Limit {{ product.max_order_quantity }} per order.

Only {{ quantityOfStock }} item(s) left.

Please message the shop owner for order details.
Description
Shipping & Payment
Description


S539 Specification
Akuvox S539 video door phone, featuring a terraced surface, a multi-functional camera module, and over 15 access control methods, is innovatively built in with an avatar. More convenient, more secure, and more interactive. The Metaverse-Intercom era is coming with S539.
Physical & Power
  • Front Panel: Aluminum
  • Display: 10 Inch IPS LCD
  • Main Camera: 5M pixels, with starlight
  • Light Sensor: Support
  • Motion Sensor: Support
  • ToF Sensor: Support
  • Wiegand Port: Support
  • RS485 Port: Support
  • Line Out: Support
  • RF Card Reader: 13.56MHz & 125kHz
  • Relays Out: 3
  • Inputs: 3
  • Microphone: 2
  • Speaker: 2
  • Reset Button: 1
  • BLE: Support
  • Ethernet port: 1xRJ45, 10/100Mbps adaptive
  • IEEE 802.3at PoE+
  • Power: DC12V / 3A or DC24V / 1.5A
  • IP & IK Level: IP66 & IK08
  • Installation: Flush-mounted & Wall-mounted
  • Flush-mounted DIM: 363.5x179.8x64mm
  • Wall-mounted DIM: 367.5x183x35.5mm
  • Working Humidity: 10~90%
  • Working Temperature: -30°C ~ +55°C
  • Storage Temperature: -30°C ~ +70°C
Audio
  • SIP v1 (RFC2543), SIP v2 (RFC3261)
  • Narrowband audio codec: G.711a, G.711μ, G.729
  • Wideband audio codec: G.722
  • DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
  • Echo Cancellation
  • Voice Activation Detection
  • Comfort Noise Generator
Video
  • Sensor: 1/2.7”, CMOS for main camera
  • Pixels: CIF, QCIF, VGA, 4CIF, 720p, 1080p
  • Video codec: H.264
  • Video technology: HDR
  • Video resolution: up to 1920x1080p
  • Max. image transfer rate: 1080p – 30fps
  • Viewing angle: 120°(H) / 72°(V)
  • Compatible to 3rd-Party-Video components, e.g. NVRs
Networking & Protocol
  • Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
  • Android OS for any 3rd party software or customization
  • Relays controlled individually by DTMF tones
  • Multi-way Unlock: Face, Card, PIN, BLE & QR code
  • Camera permanently operational
  • Auto-night mode with LED illumination
  • White balance: auto
  • Minimum illumination: 0.1LUX
Deployment & Maintenance
  • Auto-Provisioning
  • Web management portal
  • Web-based packet dump
  • Configuration backup / restore
  • Entry log export
  • Access table export / import
  • Firmware upgrade
  • System logs (include door access logs)
Application Scenario
  • Provides resident / visitor access control for buildings such as condominiums, apartment buildings, office buildings, gated communities and industrial buildings
