Akuvox S565 10-Inch Linux SIP Video Indoor Monitor

Akuvox S565 10-Inch Linux SIP Video Indoor Monitor

The S565 is a 10-inch SIP video indoor monitor that runs on the Linux OS. It features a stylish industrial design and a high-resolution touchscreen display, supporting high-quality video & audio communication and is suitable for mid-range housing markets.

{{shoplineProductReview.avg_score}}( {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}} )
{{amazonProductReview.avg_rating}}( ({{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}) )
{{ title.name_translations | translateModel }} : {{variationName[$index] | translateModel}}
Quantity
The maximum quantity per submit is 99999
This quantity is invalid, please enter a valid quantity.
Sold Out

Not enough stock.
Your item was not added to your cart.

Not enough stock.
Please adjust your quantity.

{{'products.quick_cart.out_of_number_hint'| translate}}

{{'product.preorder_limit.hint'| translate}}

Limit {{ product.max_order_quantity }} per order.

Only {{ quantityOfStock }} item(s) left.

Please message the shop owner for order details.
Description
Shipping & Payment
Description


S565 Specification
The S565 is a 10-inch SIP video indoor monitor that runs on the Linux OS. It features a stylish industrial design and a high-resolution touchscreen display, supporting high-quality video & audio communication and is suitable for mid-range housing markets.
Physical & Power
  • Microphone: Dual microphones
  • Speaker: One speaker
  • Ethernet Ports: 2xRJ45,10/100Mbps adaptive
  • POE: 802.3af Power-over-Ethernet
  • Power: 12V DC Connector
  • Installation: Wall-mounted & Desktop
  • Dimension: 278x164x22.8 mm
  • Working Humidity: 10~90%
  • Working Temperature: -10°C ~ +45°C
  • Storage Temperature: -20°C ~ +70°C
  • Front panel: Plastic
  • RAM / ROM: 128MB / 256MB
  • Display: 10 Inch IPS LCD 1280x800 resolurion
  • Screen: 10 Inch capacitive touch screen
  • Wi-Fi: IEEE802.11 b/g/n, @2.4GHz
  • RS485 port: Support
  • Relay out: 1
  • Bell in: 1
  • I/O: 8
Touch Screen & Display
  • Display Mode: Normally white, Transmissive
  • LCD Size: 10inch (Diagonal)
  • Resolution: 1280x800
  • Contrast ratio: 900:1
  • Luminance: 350 cd/m²
  • Viewing Angle: 80° Left, 80° Right,
  • 80° Upper, 80° Lower
  • Touch Screen: Projected capacitive
Audio
  • SIP v1 (RFC2543), SIP v2 (RFC3261)
  • Narrowband audio codec: G.711a, G.711μ, G.729
  • Broadband audio codec: G.722
  • DTMF: Out-of-band DTMF (RFC2833), SIP Info
  • Echo Cancellation
Video
  • Streaming formats: H.264
Networking
  • Protocols support: IPv4, HTTP, HTTPS, FTP, TFTP, SNMP, DNS, SNTP, RTSP, SRTP, RTP, TCP, UDP, TLS, ICMP, DHCP, ARP
Deployment & Maintenance
  • Auto-Provisioning
  • Web management portal
  • Web-based packet dump
  • Configuration backup / restore
  • Firmware upgrade
  • System logs (including door access logs)
Application Scenario
  • Villas
  • Apartment complexes
  • Home automation systems
  • Modern interiors
